Muzzle Velocity
2,200
fps
Muzzle Energy
1,827
ft-lbs
Ballistic Coefficient
0.241 G1
G1
Sectional Density
0.256
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,200fps | 1,827ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 1,874fps | 1,326ft-lbs | 0 | 0 | 2 | 0.148 |
| 200 yd | 1,582fps | 945ft-lbs | -8.5 | -4.1 | 8.7 | 0.322 |
| 300 yd | 1,335fps | 673ft-lbs | -31 | -9.9 | 21.1 | 0.529 |
| 400 yd | 1,147fps | 496ft-lbs | -73.1 | -17.5 | 39.9 | 0.772 |
| 500 yd | 1,025fps | 396ft-lbs | -141.7 | -27.1 | 64.8 | 1.05 |
| 600 yd | 943fps | 336ft-lbs | -243.2 | -38.7 | 94.6 | 1.356 |
| 700 yd | 881fps | 293ft-lbs | -383.9 | -52.4 | 128.7 | 1.686 |
| 800 yd | 829fps | 259ft-lbs | -569.5 | -68 | 166.6 | 2.037 |
| 900 yd | 783fps | 231ft-lbs | -805.8 | -85.5 | 208.3 | 2.411 |
| 1000 yd | 741fps | 207ft-lbs | -1099.2 | -105 | 253.9 | 2.806 |
Bullet Information
ManufacturerWinchester
Bullet170gr Power-Point
Diameter0.308" (7.62mm)
ConstructionSoft Point
BC (G1)0.241 G1
Sectional Density0.256
Load Information
More .30-30 Win Loads
Remington
4xCore-Lokt
.30-30 Win · 170gr · Core-Lokt Hollow Point
MV: 2,200fps
BC: 0.254 G1
Energy: 1,827ft-lbs
Type: Hunting
Remington
1xCore-Lokt
.30-30 Win · 170gr · Core-Lokt Soft Point
MV: 2,200fps
BC: 0.254 G1
Energy: 1,827ft-lbs
Type: Hunting
Nosler
Whitetail Country
.30-30 Win · 150gr · Solid Base
MV: Not published
BC: 0.398 G1
Energy: —
Type: Hunting
Hornady
LEVERevolution
.30-30 Win · 140gr · MonoFlex
MV: 2,526fps
BC: 0.295 G1
Energy: 1,983ft-lbs
Type: Hunting
Hornady
LEVERevolution
.30-30 Win · 140gr · MonoFlex
MV: 2,465fps
BC: 0.295 G1
Energy: 1,889ft-lbs
Type: Hunting
Hornady
LEVERevolution
.30-30 Win · 160gr · FTX
MV: 2,400fps
BC: 0.330 G1
Energy: 2,046ft-lbs
Type: Hunting
Other Loads Using the Power-Point
Winchester
Power-Point - 250th Anniversary Edition
.30-30 Win · 170gr · Power-Point
MV: 2,200fps
BC: 0.241 G1
Energy: 1,827ft-lbs
Type: Hunting
Similar Loads in Other Cartridges
Hornady
7xMatch
.308 Winchester · 168gr · ELD Match
MV: 2,700fps
BC: 0.263 G7
Energy: 2,719ft-lbs
Type: Match
Norma
4xBondstrike
.30-06 Sprg · 180gr · Bondstrike
MV: 2,756fps
BC: 0.615 G1
Energy: 3,035ft-lbs
Type: Hunting
Norma
4xOryx
.308 Winchester · 165gr · Oryx
MV: 2,740fps
BC: 0.333 G1
Energy: 2,750ft-lbs
Type: Hunting
Hornady
3xAmerican Whitetail Tipped
.300 PRC · 165gr · SST
MV: 3,200fps
BC: 0.225 G7
Energy: 3,751ft-lbs
Type: Hunting
Nosler
3xBallistic Tip Hunting
.30-06 Sprg · 165gr · Ballistic Tip Hunting
MV: 2,950fps
BC: 0.475 G1
Energy: 3,188ft-lbs
Type: Hunting
Nosler
2xTrophy Grade
.30-06 Sprg · 165gr · AccuBond
MV: 2,950fps
BC: 0.475 G1
Energy: 3,188ft-lbs
Type: Hunting
