Muzzle Velocity
2,650
fps
Muzzle Energy
2,183
ft-lbs
Ballistic Coefficient
0.478 G1
G1
Sectional Density
0.287
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,650fps | 2,183ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,463fps | 1,886ft-lbs | 0 | 0 | 0.7 | 0.117 |
| 200 yd | 2,284fps | 1,621ft-lbs | -4.2 | -2 | 3.1 | 0.244 |
| 300 yd | 2,112fps | 1,387ft-lbs | -15.2 | -4.8 | 7.2 | 0.38 |
| 400 yd | 1,948fps | 1,180ft-lbs | -33.9 | -8.1 | 13.3 | 0.528 |
| 500 yd | 1,792fps | 998ft-lbs | -61.8 | -11.8 | 21.6 | 0.689 |
| 600 yd | 1,645fps | 841ft-lbs | -100.5 | -16 | 32.5 | 0.864 |
| 700 yd | 1,509fps | 708ft-lbs | -152.2 | -20.8 | 46.1 | 1.054 |
| 800 yd | 1,385fps | 596ft-lbs | -219.1 | -26.2 | 62.7 | 1.262 |
| 900 yd | 1,275fps | 505ft-lbs | -304.2 | -32.3 | 82.5 | 1.488 |
| 1000 yd | 1,181fps | 434ft-lbs | -410.7 | -39.2 | 105.7 | 1.733 |
Bullet Information
ManufacturerWinchester
Bullet140gr Extreme Point
Diameter0.264" (6.5mm)
ConstructionSoft Point
BC (G1)0.478 G1
Sectional Density0.287
