Winchester
Power-Point
.325 Winchester Short Magnum · 220gr · Power-Point
Muzzle Velocity
2,840
fps
Muzzle Energy
3,939
ft-lbs
Ballistic Coefficient
0.388 G1
G1
Sectional Density
0.301
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,840fps | 3,939ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,601fps | 3,305ft-lbs | 0 | 0 | 0.8 | 0.11 |
| 200 yd | 2,375fps | 2,754ft-lbs | -3.7 | -1.7 | 3.5 | 0.231 |
| 300 yd | 2,159fps | 2,277ft-lbs | -13.5 | -4.3 | 8.2 | 0.364 |
| 400 yd | 1,956fps | 1,868ft-lbs | -30.8 | -7.4 | 15.3 | 0.51 |
| 500 yd | 1,764fps | 1,520ft-lbs | -57.2 | -10.9 | 25.2 | 0.671 |
| 600 yd | 1,587fps | 1,230ft-lbs | -94.9 | -15.1 | 38.1 | 0.85 |
| 700 yd | 1,427fps | 994ft-lbs | -146.4 | -20 | 54.7 | 1.05 |
| 800 yd | 1,287fps | 809ft-lbs | -215 | -25.7 | 75.1 | 1.272 |
| 900 yd | 1,171fps | 670ft-lbs | -304.7 | -32.3 | 99.6 | 1.516 |
| 1000 yd | 1,083fps | 573ft-lbs | -419.7 | -40.1 | 127.9 | 1.783 |
Bullet Information
ManufacturerWinchester
Bullet220gr Power-Point
Diameter0.323"
ConstructionSoft Point
BC (G1)0.388 G1
Sectional Density0.301
Load Information
Cartridge.325 Winchester Short Magnum
ManufacturerWinchester
Product LinePower-Point
CategoryHunting
SKUX325WSM
