Muzzle Velocity

2,700

fps

Muzzle Energy

2,913

ft-lbs

Ballistic Coefficient

0.453 G1

Sectional Density

0.271

Bullet Drop (inches)

Ballistic Trajectory

100yd zero, sea level, 59°F, 10 mph crosswind

Range	Velocity	Energy	Drop (in)	Drop (MOA)	Wind (in)	TOF
0 yd	2,700fps	2,913ft-lbs	-1.5	0	0	0
100 yd	2,501fps	2,499ft-lbs	0	0	0.8	0.115
200 yd	2,310fps	2,133ft-lbs	-4.1	-1.9	3.2	0.24
300 yd	2,128fps	1,810ft-lbs	-14.7	-4.7	7.4	0.376
400 yd	1,954fps	1,527ft-lbs	-33	-7.9	13.8	0.523
500 yd	1,790fps	1,280ft-lbs	-60.4	-11.5	22.4	0.683
600 yd	1,635fps	1,069ft-lbs	-98.7	-15.7	33.8	0.858
700 yd	1,493fps	890ft-lbs	-150	-20.5	48	1.051
800 yd	1,364fps	743ft-lbs	-217	-25.9	65.5	1.261
900 yd	1,251fps	625ft-lbs	-302.6	-32.1	86.4	1.491
1000 yd	1,157fps	535ft-lbs	-410.6	-39.2	110.8	1.741

Bullet Information

ManufacturerBarnes

Bullet180gr TTSX

Diameter0.308" (7.62mm)

ConstructionMonolithic

BC (G7)0.245 G7

BC (G1)0.453 G1

Sectional Density0.271

Load Information

Cartridge.30-06 Springfield

ManufacturerFederal Premium

Product LineBarnes TSX

CategoryHunting

SKUP3006AE
