Muzzle Velocity
4,199
fps
Muzzle Energy
783
ft-lbs
Ballistic Coefficient
0.185
G1
Sectional Density
0.097
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 4,199fps | 783ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 3,540fps | 557ft-lbs | 0 | 0 | 1.1 | 0.078 |
| 200 yd | 2,973fps | 392ft-lbs | -1.3 | -0.6 | 4.8 | 0.17 |
| 300 yd | 2,472fps | 271ft-lbs | -6.6 | -2.1 | 11.8 | 0.281 |
| 400 yd | 2,023fps | 182ft-lbs | -17.6 | -4.2 | 22.8 | 0.415 |
| 500 yd | 1,628fps | 118ft-lbs | -37.3 | -7.1 | 39.3 | 0.581 |
| 600 yd | 1,305fps | 76ft-lbs | -70.4 | -11.2 | 63.1 | 0.787 |
| 700 yd | 1,086fps | 52ft-lbs | -124 | -16.9 | 95.2 | 1.041 |
| 800 yd | 962fps | 41ft-lbs | -207 | -24.7 | 134.5 | 1.336 |
| 900 yd | 878fps | 34ft-lbs | -327.5 | -34.7 | 179.5 | 1.663 |
| 1000 yd | 812fps | 29ft-lbs | -493.1 | -47.1 | 229.6 | 2.019 |
Bullet Information
ManufacturerHornady
Bullet20gr V-MAX
Diameter0.172" (4.5mm)
ConstructionHollow Point
BC (G1)0.185 G1
Sectional Density0.097
Load Information
Cartridge.17 Remington
ManufacturerNorma
Product LineHornady V-MAX
CategoryHunting
Test Barrel24"
SKU20143022
