Muzzle Velocity
2,850
fps
Muzzle Energy
2,254
ft-lbs
Ballistic Coefficient
0.428 G1
G1
Sectional Density
0.256
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,850fps | 2,254ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,632fps | 1,923ft-lbs | 0 | 0 | 0.8 | 0.11 |
| 200 yd | 2,425fps | 1,632ft-lbs | -3.5 | -1.7 | 3.1 | 0.228 |
| 300 yd | 2,227fps | 1,377ft-lbs | -13 | -4.1 | 7.3 | 0.357 |
| 400 yd | 2,039fps | 1,153ft-lbs | -29.5 | -7 | 13.6 | 0.498 |
| 500 yd | 1,860fps | 960ft-lbs | -54.3 | -10.4 | 22.2 | 0.652 |
| 600 yd | 1,692fps | 794ft-lbs | -89.3 | -14.2 | 33.4 | 0.821 |
| 700 yd | 1,536fps | 655ft-lbs | -136.4 | -18.6 | 47.6 | 1.008 |
| 800 yd | 1,395fps | 540ft-lbs | -198.3 | -23.7 | 65.2 | 1.213 |
| 900 yd | 1,272fps | 449ft-lbs | -278.1 | -29.5 | 86.4 | 1.438 |
| 1000 yd | 1,169fps | 379ft-lbs | -379.4 | -36.2 | 111.2 | 1.684 |
Bullet Information
ManufacturerWinchester
Bullet125gr Extreme Point
Diameter0.264" (6.5mm)
ConstructionSoft Point
BC (G1)0.428 G1
Sectional Density0.256
Load Information
More 6.5 CM Loads
Hornady
3xMatch
6.5 Creedmoor · 147gr · ELD Match
MV: 2,695fps
BC: 0.351 G7
Energy: 2,370ft-lbs
Type: Match
Federal Premium
2xTerminal Ascent
6.5 Creedmoor · 130gr · Terminal Ascent
MV: 2,800fps
BC: 0.263 G7
Energy: 2,263ft-lbs
Type: Hunting
Nosler
2xBallistic Tip Hunting
6.5 Creedmoor · 140gr · Ballistic Tip Hunting
MV: 2,650fps
BC: 0.509 G1
Energy: 2,183ft-lbs
Type: Hunting
Barnes
1xVOR-TX Reduced Recoil
6.5 Creedmoor · 100gr · TTSX
MV: 2,760fps
BC: 0.351 G1
Energy: 1,691ft-lbs
Type: Hunting
Hornady
Hornady International
6.5 Creedmoor · 120gr · ECX
MV: Not published
BC: 0.360 G1
Energy: —
Type: Hunting
Nosler
Whitetail Country
6.5 Creedmoor · 140gr · Solid Base
MV: Not published
Energy: —
Type: Hunting
Other Loads Using the Extreme Point
Winchester
Copper Impact
6.5 PRC · 125gr · Extreme Point
MV: 3,100fps
BC: 0.428 G1
Energy: 2,667ft-lbs
Type: Hunting
Similar Loads in Other Cartridges
Federal Premium
3xTerminal Ascent
6.5 CM +P · 130gr · Terminal Ascent
MV: 3,100fps
BC: 0.263 G7
Energy: 2,774ft-lbs
Type: Hunting
Federal Premium
1xBarnes LRX
6.5 CM +P · 127gr · LRX
MV: 3,100fps
BC: 0.468 G1
Energy: 2,710ft-lbs
Type: Hunting
Nosler
1xTrophy Grade
.264 Win Mag · 130gr · AccuBond
MV: 3,100fps
BC: 0.488 G1
Energy: 2,774ft-lbs
Type: Hunting
Federal Premium
1xTerminal Ascent
6.5 PRC · 130gr · Terminal Ascent
MV: 3,000fps
BC: 0.263 G7
Energy: 2,597ft-lbs
Type: Hunting
Federal Premium
1xFusion MSR
6.5 Grendel · 120gr · Fusion
MV: 2,600fps
BC: 0.340 G1
Energy: 1,801ft-lbs
Type: Hunting
Hornady
1xCustom
6.5 Grendel · 123gr · SST
MV: 2,580fps
BC: 0.510 G1
Energy: 1,818ft-lbs
Type: Hunting
