Muzzle Velocity
2,756
fps
Muzzle Energy
2,867
ft-lbs
Ballistic Coefficient
0.249
G7
Sectional Density
0.256
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,756fps | 2,867ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,571fps | 2,496ft-lbs | 0 | 0 | 0.7 | 0.113 |
| 200 yd | 2,394fps | 2,163ft-lbs | -3.8 | -1.8 | 2.8 | 0.234 |
| 300 yd | 2,223fps | 1,866ft-lbs | -13.6 | -4.3 | 6.5 | 0.364 |
| 400 yd | 2,061fps | 1,602ft-lbs | -30.5 | -7.3 | 12 | 0.504 |
| 500 yd | 1,904fps | 1,369ft-lbs | -55.6 | -10.6 | 19.5 | 0.655 |
| 600 yd | 1,754fps | 1,161ft-lbs | -90.3 | -14.4 | 29.3 | 0.819 |
| 700 yd | 1,609fps | 977ft-lbs | -136.3 | -18.6 | 41.5 | 0.998 |
| 800 yd | 1,470fps | 815ft-lbs | -195.8 | -23.4 | 56.7 | 1.193 |
| 900 yd | 1,336fps | 674ft-lbs | -271.5 | -28.8 | 75.2 | 1.407 |
| 1000 yd | 1,210fps | 552ft-lbs | -366.6 | -35 | 97.6 | 1.643 |
Bullet Information
ManufacturerLapua
Bullet170gr Lock Base
Diameter0.308" (7.62mm)
Construction—
BC (G7)0.249 G7
BC (G1)0.498 G1
Sectional Density0.256
Load Information
