Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,800fps | 1,114ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,297fps | 749ft-lbs | 0 | 0 | 2 | 0.118 |
| 200 yd | 1,849fps | 486ft-lbs | -5.2 | -2.5 | 8.7 | 0.264 |
| 300 yd | 1,467fps | 306ft-lbs | -20.8 | -6.6 | 22 | 0.446 |
| 400 yd | 1,178fps | 197ft-lbs | -52.8 | -12.6 | 43.5 | 0.676 |
| 500 yd | 1,009fps | 145ft-lbs | -109.8 | -21 | 73.4 | 0.953 |
| 600 yd | 909fps | 117ft-lbs | -200.8 | -32 | 109.9 | 1.267 |
| 700 yd | 834fps | 99ft-lbs | -334.1 | -45.6 | 151.8 | 1.613 |
| 800 yd | 771fps | 85ft-lbs | -517.4 | -61.8 | 199 | 1.988 |
| 900 yd | 716fps | 73ft-lbs | -759.4 | -80.6 | 251.3 | 2.392 |
| 1000 yd | 667fps | 63ft-lbs | -1069.6 | -102.1 | 309.1 | 2.828 |
Bullet Information
Load Information
