Winchester
Power Max Bonded
.308 Winchester · 180gr · Bonded Rapid Expansion Protected
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,620fps | 2,743ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,396fps | 2,294ft-lbs | 0 | 0 | 0.9 | 0.12 |
| 200 yd | 2,183fps | 1,904ft-lbs | -4.6 | -2.2 | 3.9 | 0.251 |
| 300 yd | 1,981fps | 1,568ft-lbs | -16.5 | -5.2 | 9.1 | 0.395 |
| 400 yd | 1,791fps | 1,281ft-lbs | -37.3 | -8.9 | 17 | 0.555 |
| 500 yd | 1,614fps | 1,041ft-lbs | -68.9 | -13.2 | 27.9 | 0.731 |
| 600 yd | 1,453fps | 844ft-lbs | -114 | -18.1 | 42.3 | 0.927 |
| 700 yd | 1,311fps | 687ft-lbs | -175.6 | -23.9 | 60.4 | 1.145 |
| 800 yd | 1,193fps | 568ft-lbs | -257.4 | -30.7 | 82.5 | 1.385 |
| 900 yd | 1,100fps | 483ft-lbs | -363.7 | -38.6 | 108.6 | 1.647 |
| 1000 yd | 1,031fps | 424ft-lbs | -498.7 | -47.6 | 138.1 | 1.93 |
