Muzzle Velocity
3,120
fps
Muzzle Energy
3,242
ft-lbs
Ballistic Coefficient
0.496 G1
G1
Sectional Density
0.279
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 3,120fps | 3,242ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,920fps | 2,839ft-lbs | 0 | 0 | 0.6 | 0.099 |
| 200 yd | 2,728fps | 2,479ft-lbs | -2.6 | -1.2 | 2.4 | 0.206 |
| 300 yd | 2,545fps | 2,157ft-lbs | -9.8 | -3.1 | 5.5 | 0.32 |
| 400 yd | 2,369fps | 1,869ft-lbs | -22.5 | -5.4 | 10.1 | 0.442 |
| 500 yd | 2,200fps | 1,612ft-lbs | -41.3 | -7.9 | 16.3 | 0.573 |
| 600 yd | 2,038fps | 1,383ft-lbs | -67.4 | -10.7 | 24.3 | 0.715 |
| 700 yd | 1,883fps | 1,181ft-lbs | -101.8 | -13.9 | 34.3 | 0.868 |
| 800 yd | 1,736fps | 1,004ft-lbs | -146 | -17.4 | 46.6 | 1.034 |
| 900 yd | 1,598fps | 850ft-lbs | -201.8 | -21.4 | 61.4 | 1.214 |
| 1000 yd | 1,470fps | 720ft-lbs | -271.3 | -25.9 | 78.9 | 1.41 |
Bullet Information
ManufacturerWinchester
Bullet150gr Rapid Controlled Expansion Polymer Tip
Diameter0.277"
ConstructionBonded
BC (G1)0.496 G1
Sectional Density0.279
Load Information
Cartridge.270 Winchester Short Magnum
ManufacturerWinchester
Product LineBallistic Silvertip
CategoryHunting
SKUSBST2705A
