Muzzle Velocity
2,260
fps
Muzzle Energy
1,701
ft-lbs
Ballistic Coefficient
0.223 G1
G1
Sectional Density
0.168
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,260fps | 1,701ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 1,903fps | 1,207ft-lbs | 0 | 0 | 2.1 | 0.145 |
| 200 yd | 1,586fps | 838ft-lbs | -8.2 | -3.9 | 9.1 | 0.317 |
| 300 yd | 1,320fps | 580ft-lbs | -30.4 | -9.7 | 22.3 | 0.525 |
| 400 yd | 1,125fps | 421ft-lbs | -72.6 | -17.3 | 42.5 | 0.773 |
| 500 yd | 1,003fps | 335ft-lbs | -142.3 | -27.2 | 69.1 | 1.056 |
| 600 yd | 922fps | 283ft-lbs | -246.4 | -39.2 | 100.7 | 1.369 |
| 700 yd | 859fps | 246ft-lbs | -391.5 | -53.4 | 136.7 | 1.706 |
| 800 yd | 806fps | 216ft-lbs | -583.6 | -69.7 | 176.9 | 2.067 |
| 900 yd | 759fps | 192ft-lbs | -829.5 | -88 | 221.2 | 2.452 |
| 1000 yd | 717fps | 171ft-lbs | -1136 | -108.5 | 269.7 | 2.86 |
Bullet Information
ManufacturerWinchester
Bullet150gr Extreme Point
Diameter0.357"
ConstructionSoft Point
BC (G1)0.223 G1
Sectional Density0.168
Load Information
