Winchester
Deer Season XP
.270 Winchester Short Magnum · 130gr · Extreme Point
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 3,275fps | 3,096ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 3,014fps | 2,622ft-lbs | 0 | 0 | 0.7 | 0.096 |
| 200 yd | 2,768fps | 2,211ft-lbs | -2.3 | -1.1 | 2.8 | 0.199 |
| 300 yd | 2,535fps | 1,855ft-lbs | -9.2 | -2.9 | 6.7 | 0.313 |
| 400 yd | 2,314fps | 1,546ft-lbs | -21.5 | -5.1 | 12.3 | 0.436 |
| 500 yd | 2,104fps | 1,278ft-lbs | -40.3 | -7.7 | 20.1 | 0.572 |
| 600 yd | 1,906fps | 1,048ft-lbs | -67 | -10.7 | 30.4 | 0.722 |
| 700 yd | 1,720fps | 853ft-lbs | -103.3 | -14.1 | 43.4 | 0.888 |
| 800 yd | 1,548fps | 692ft-lbs | -151.4 | -18.1 | 59.7 | 1.072 |
| 900 yd | 1,394fps | 561ft-lbs | -214.1 | -22.7 | 79.5 | 1.276 |
| 1000 yd | 1,260fps | 458ft-lbs | -294.7 | -28.1 | 103.3 | 1.503 |
Bullet Information
Load Information
