Muzzle Velocity
2,986
fps
Muzzle Energy
3,365
ft-lbs
Ballistic Coefficient
0.324
G1
Sectional Density
0.301
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,986fps | 3,365ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,692fps | 2,735ft-lbs | 0 | 0 | 0.9 | 0.106 |
| 200 yd | 2,417fps | 2,204ft-lbs | -3.3 | -1.6 | 4 | 0.223 |
| 300 yd | 2,158fps | 1,757ft-lbs | -12.6 | -4 | 9.4 | 0.355 |
| 400 yd | 1,915fps | 1,384ft-lbs | -29.4 | -7 | 17.7 | 0.502 |
| 500 yd | 1,691fps | 1,079ft-lbs | -55.7 | -10.6 | 29.4 | 0.669 |
| 600 yd | 1,489fps | 836ft-lbs | -94.3 | -15 | 45 | 0.858 |
| 700 yd | 1,313fps | 651ft-lbs | -148.6 | -20.3 | 65.1 | 1.073 |
| 800 yd | 1,172fps | 518ft-lbs | -223.1 | -26.6 | 90.1 | 1.316 |
| 900 yd | 1,068fps | 431ft-lbs | -323 | -34.3 | 119.7 | 1.584 |
| 1000 yd | 995fps | 374ft-lbs | -453.3 | -43.3 | 153.4 | 1.876 |
Bullet Information
ManufacturerNorma
Bullet170gr Oryx
Diameter0.284" (7mm)
ConstructionBonded
BC (G1)0.324 G1
Sectional Density0.301
Load Information
Cartridge7mm Weatherby Magnum
ManufacturerNorma
Product LineOryx
CategoryHunting
Test Barrel24"
SKU20171072
