Muzzle Velocity
2,900
fps
Muzzle Energy
2,614
ft-lbs
Ballistic Coefficient
0.617 G1
G1
Sectional Density
0.287
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 2,900fps | 2,614ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,746fps | 2,344ft-lbs | 0 | 0 | 0.5 | 0.106 |
| 200 yd | 2,598fps | 2,097ft-lbs | -3.1 | -1.5 | 2.1 | 0.219 |
| 300 yd | 2,454fps | 1,872ft-lbs | -11.4 | -3.6 | 4.8 | 0.337 |
| 400 yd | 2,315fps | 1,665ft-lbs | -25.4 | -6.1 | 8.7 | 0.463 |
| 500 yd | 2,180fps | 1,477ft-lbs | -46 | -8.8 | 14 | 0.597 |
| 600 yd | 2,050fps | 1,306ft-lbs | -73.8 | -11.8 | 20.8 | 0.739 |
| 700 yd | 1,924fps | 1,151ft-lbs | -110 | -15 | 29.2 | 0.89 |
| 800 yd | 1,804fps | 1,011ft-lbs | -155.5 | -18.6 | 39.3 | 1.051 |
| 900 yd | 1,689fps | 886ft-lbs | -211.8 | -22.5 | 51.4 | 1.223 |
| 1000 yd | 1,580fps | 775ft-lbs | -280.2 | -26.8 | 65.5 | 1.407 |
Bullet Information
ManufacturerWinchester
Bullet140gr BC MAX
Diameter0.264" (6.5mm)
ConstructionOther
BC (G1)0.617 G1
Sectional Density0.287
