Winchester
Power Max Bonded
.270 Winchester Short Magnum · 130gr · Bonded Rapid Expansion Protected
Bullet Drop (inches)
Ballistic Trajectory
100yd zero, sea level, 59°F, 10 mph crosswind
| Range | Velocity | Energy | Drop (in) | Drop (MOA) | Wind (in) | TOF |
|---|---|---|---|---|---|---|
| 0 yd | 3,275fps | 3,096ft-lbs | -1.5 | 0 | 0 | 0 |
| 100 yd | 2,975fps | 2,555ft-lbs | 0 | 0 | 0.8 | 0.096 |
| 200 yd | 2,696fps | 2,097ft-lbs | -2.4 | -1.2 | 3.3 | 0.202 |
| 300 yd | 2,433fps | 1,708ft-lbs | -9.7 | -3.1 | 7.8 | 0.319 |
| 400 yd | 2,185fps | 1,377ft-lbs | -22.8 | -5.4 | 14.6 | 0.449 |
| 500 yd | 1,951fps | 1,099ft-lbs | -43.3 | -8.3 | 24.1 | 0.595 |
| 600 yd | 1,734fps | 868ft-lbs | -72.9 | -11.6 | 36.6 | 0.758 |
| 700 yd | 1,537fps | 681ft-lbs | -114.2 | -15.6 | 52.9 | 0.942 |
| 800 yd | 1,362fps | 535ft-lbs | -170.2 | -20.3 | 73.3 | 1.149 |
| 900 yd | 1,216fps | 427ft-lbs | -245 | -26 | 98.3 | 1.383 |
| 1000 yd | 1,104fps | 352ft-lbs | -343.4 | -32.8 | 127.8 | 1.642 |
Bullet Information
Load Information
